WIS-PLC
The WIS micro-controller combines the benefits of the Open Source Hardware to provide a reliable and customisable solution for your industry.
OVERVIEW
x8 Inputs
x4 Convertible
x4 Digital isolated
x5 Outputs
x4 Digital
x1 Convertible Digital isolated/PWM/Analog
Communications: I2C, RS485 (FD), Ethernet(2), WiFi, BLE, Serial TTL, SPI,UPS,RTC,μSD *(GSM-GPRS-4G-NB, LoRa, DALI, GPRS-4, CAN,GPS)
Powerful and standard industrial communications
Wireless communications
WiFi & Bluetooth Available
External Buses Available
Ethernet, I2C, SPI, RS485 half-duplex or UART
LoRa and Narrow Band options
DIRECTIVES
RoHS
EN 50581
LVD
EN 61010-1, EN 61010-2-201
EMC
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3, IEC 61000-6-4
RED
EN 301 489-1, EN 301 489-52, EN 301 489-3, EN 301 489-17, EN 300 328, ETSI EN 300 220-1, ETSI EN 300 220-2, EN 301 908-1, EN 301 908-2, EN 301 908-13, EN 301 511
Safety
IEC62311
DIRECTIVES
RoHS
EN 50581
LVD
EN 61010-1, EN 61010-2-201
EMC
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3, IEC 61000-6-4
RED
EN 301 489-1, EN 301 489-52, EN 301 489-3, EN 301 489-17, EN 300 328, ETSI EN 300 220-1, ETSI EN 300 220-2, EN 301 908-1, EN 301 908-2, EN 301 908-13, EN 301 511
Safety
IEC62311
CONNECTION DATA
Wire Connection Cross Section AWG, min – max
AWG 24 – AWG 14
Solid, min H05(07) V-U, min – max
0,2 mm2 – 1,5 mm2
Stranded, min H07 V-R, min – max
0,2 mm2 – 2,5 mm2
Flexible, min H05(07) V-K, min – max
0,2 mm2 – 2,5 mm2
w. plastic collar ferrule, DIN 46228 pt.4, min – max
0,25 mm2 – 2,5 mm2
Ethernet Interface
RJ45 Female Socket
USB (Programming Interface)
Micro-USB Type B Female Socket
External antenna connections
SMA Female
Other
μSD Interface, Reset Button, Real Time Clock
(CR1220 Battery not included)
